DC distribution with gPV string fuses, DC surge protection and load-break isolation, built to your string plan and tested before dispatch.
Specifications
| Voltage class | Up to 1000 / 1500 V DC |
| Protection | gPV fuses, DC SPD Type II (I+II on request), isolator |
| Enclosure | IP65 outdoor / IP54 indoor |
| Testing | Continuity, IR and functional checks, report supplied |
Indicative values. Final specifications are confirmed against your order.
Variants
| 1-in 1-out to 4-in 1-out | Residential and small commercial strings |
| 6-in 1-out to 12-in 1-out | Commercial and industrial arrays |
| Custom string plans | Built to your SLD with monitoring-ready wiring |
Standards & certifications
Designed and built with reference to applicable Indian and IEC standards (IS 2062, IS 875, IS 4759 / ISO 1461, IS/IEC 61439, IS/IEC 60529 as relevant to this product). Certification documents for the current production batch are available on request and will be published here as files are finalised.
Downloads
Current revision, uploaded by our team as specifications change.
Certification documents for the current production batch.
Frequently asked questions
Which SPD type do I need?
Type II is standard; Type I+II where the array is highly lightning-exposed. Our engineers confirm against your site.
Do you use branded fuses?
Yes, gPV fuses from reputed makes or our own batch-tested Envera range, your choice at quotation.
Is a test report included?
Every DCDB ships with continuity, insulation-resistance and functional test results.
How do I get pricing?
Use the Enquire button above or the contact form; volume and dealer pricing available.
Are datasheets available?
Yes, current-revision datasheets are supplied with quotations and added to this page as files are finalised.
